Fan
Cit 100T
Description
Constructive Details
Fixing Bracket
Allows for the support, fixation, and alignment of the unit to a wall or other surfaces.
Forward-curved blades
It is designed with blades that curve in the direction of rotation. It delivers a high airflow at low to medium pressure, ensuring quiet operation and a compact design.
Metal casing
Galvanized Steel Impeller
Epoxy-coated casing
Motor Insulation Class F
The F insulation class allows the motor insulation to operate safely at a maximum temperature of 155°C
2-Pole Configuration
Fan Type
Centrifugal
Can operate for long periods of time, providing consistent performance. Reliable and versatile, it ensures a constant flow rate at variable pressures.
Main Functions
Air Exhaust
Motor
AC Brushless
A brushless AC fan motor is a modern and energy-efficient electric motor. It does not use carbon brushes and is electronically controlled, providing quieter operation, a longer lifespan, and precise speed control.
Features
Overheating Protection
Technical Data
Turbionaire CIT ensures an efficient airflow in a compact design, ideal for professional applications, offering high efficiency, quiet operation, and long-term stability. Its robust construction guarantees wear resistance and durability in demanding environments.
Constructive Details
Fixing Bracket
Allows for the support, fixation, and alignment of the unit to a wall or other surfaces.
Forward-curved blades
It is designed with blades that curve in the direction of rotation. It delivers a high airflow at low to medium pressure, ensuring quiet operation and a compact design.
Metal casing
Galvanized Steel Impeller
Epoxy-coated casing
Motor Insulation Class F
The F insulation class allows the motor insulation to operate safely at a maximum temperature of 155°C
2-Pole Configuration
Fan Type
Centrifugal
Can operate for long periods of time, providing consistent performance. Reliable and versatile, it ensures a constant flow rate at variable pressures.
Main Functions
Air Exhaust
Motor
AC Brushless
A brushless AC fan motor is a modern and energy-efficient electric motor. It does not use carbon brushes and is electronically controlled, providing quieter operation, a longer lifespan, and precise speed control.
